B&C Technologies HP Series Commercial - Manual (Page 15)

Installation
HP-60 Technical Specifications
14
MODEL
Metric US
CAPACITY:
Loading factor 1:10
kg lbs 27.4 60
1:12 kg lbs 22.8 50.2
1:13 kg lbs 21.1 46.4
OVERALL DIMENSIONS:
Width
mm in 880 34.6
Height mm in 1650 65
Depth mm in 1190 47
WEIGHT AND SHIPPING INFORMATION:
Net Weight
kg lbs 660 1450
Domestic shipping weight kg lbs 720 1584
CYLINDER INFORMATION:
Diameter
mm in 790 31.1
Depth mm in 560 22
Volume liters cu ft 274 9.7
Perforation size mm in 4.8 0.188
Perforation open area % % 23 23
CYLINDER SPEEDS (Programmable):
Wash
rpm g 43 0.8
Distribution rpm g 67 2
Intermediate extraction rpm g 583 150
High extract 1 rpm g 673 200
High extract 2 rpm g 753 250
High extract 3 rpm g 890 300
Units
HP-60
