Char-Broil 463210510 User Manual
Page 19
Attach cylinder insulation board to cart back brace with #10-24x1/2" screws.
Place grease tray to the cart assembly as shown.
Insert tank retainer to the holes from the bottom shelf. Attach with a hitch pin.
5
6
Qty. 1
1” Hitch Pin
Qty: 3
#10-24x1/2"
Machine Screw
Cylinder Insulation Board
Grease Tray
Tank Retainer,Wire Form
19
Stand cart upright.
