Sonoma Series™ VALUE Workcenters - Assembly Instructions for Tables with Left Front Crank
Parts for 3-Leg Tables, grouped by carton
Foot caps
Qty: 6
Side Leg Brackets
Qty: 2
There are three different Value legs.
If not put together in the correct
order, the table will not function
properly.
Legs are designated as 1, 2 or 3.
For assembly of two-piece tops, please
refer to separate instructions.
Side Entry Hex Shafts
Qty: 2
Crank Handle Hex Shaft
Qty: 1
Front Entry Hex Shaft
Qty: 1
Leveling Glides
Qty: 6
Crank Handle Assembly
Qty: 1
¾" Button head
Machine Screws
Qty: 20
5 /
32
" Allen Wrench
Qty: 1
#12 x ¾" Wood Screws
Qty: 30
Center Leg Z-Bend
Bracket
Qty: 1
Center Leg Top
Bracket
Qty: 1 Side Leg Top
Brackets
Qty: 2
A
B
E
D
F
G
H
I J
K
P Q
M
N
O
L
R
S T
U V
¾" Lock Washers
Qty: 20
Side Leg Feet
Qty: 2
(packaged
separately)
Center Leg Foot
Qty: 1
(packaged in pairs) Crossbars
Qty: 2
Crank Tubes
Qty: 2
Tabletop (size and shape differ for each model)
Qty: 1
Leg 1
Qty: 1
C
Leg 2
Qty: 1 Leg 3
Qty: 1
