13
Wine Guardian-Mounted (Integrated Installation)
NOTE: Integrated humidifiers can be mounted in either of the two side openings
of the cooling unit on the cooling or evaporator end only. If a duct connection is
in that position, move the duct connection to the top or other side. DO NOT
MOUNT THE HUMIDIFIER ON THE CONDENSER END OF THE UNIT.
1) Remove side access panel on the side of the cooling unit where you wish to mount the
humidifier.
2) Select the proper adapter plate for the cooling unit (D025, SS025, D050, SS050 and
D088, SS088 units use the same adapter plate). D200 and SS200 units require a larger
adapter plate and install on the side opening using the screws from the panel removed
above. The adapter plate allows the humidifier to be mounted in either a forward
position or back toward the center by simply rotating the adapter plate 180 degrees. (See
Figure 5.0)
3) Install a ½” flexible drain line from the bottom of the humidifier to an open drain or
connect into the drain line from the cooling unit.
4) Install a ¼” warm water line from the water supply to the connection at the top of the
humidifier. A shut off valve (not provided) is recommended to isolate the humidifier
from the water system when needed.
5) Connect the communication cable to the side of the Wine Guardian system as shown in
Figure 6 on the following page. The communication cable provides power and control
signals to the humidifier from the Wine Guardian main control panel.
6) Proceed to set-up of Remote Interface Controller within the wine cellar to re-program
for humidity control
