Freestanding Installation
1) Determine where unit will be mounted.
a. If wall mounted, use surface mount bracket (71H0572-00-D). Secure bracket to wall.
Attach humidifier to the bracket (with drain tube on bottom) using four (4) screws
provided.
b. If shelf mounted, place humidifier on shelf with drain tube on bottom. You may need to
drill a 1” diameter hole in the shelf and route the drain tube through the hole.
c. If through-the-wall mounted, frame opening to have studs 16" OC (on center). Attach the
Through-the-Wall bracket (71H0571-00-D) to the studs using drywall screws or
something similar. Attach humidifier (with drain tube on the bottom) to the bracket using
the eight (8) screws provided. Fill in any gaps between the humidifier and the wall
framing with insulation. Trim as necessary.
2) Install a ¼”water line from the water supply to connection at the top of the humidifier. A
shut-off valve (not provided) is recommended to isolate the humidifier from the water system
when needed.
3) Install a ½” flexible drain line from the bottom of the humidifier to an open drain or connect
into the drain line from the cooling unit.
For humidifier part number 99H0174-00 proceed to steps 4 and 5.
For humidifier part number 99H0185-00 proceed to steps 6 and 7.
4) Humidifier part number 99H0174-00 uses the Remote or Local Interface Controller at the
Wine Guardian system to monitor and control humidity. Plug communication cable from
humidifier into connection at Wine Guardian unit at this time. The communication cable
provides power and control signals to humidifier from Wine Guardian main control panel.
5) Proceed to set up of the Remote or Local Interface Controller at Wine Guardian unit to re-
program for humidity control.
6) Install the humidistat on the wall where it is open to the cellar and can be read easily,
approximately 60" above the floor. See section on Humidistat Mounting on page 15.
7) Plug transformer plug into wall outlet. The humidifier should now be operational.
