HS-102P pan and tilt head

Parts list

Main Assemblies

HS-102P pan & tilt head (Studio version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-HS-102P

HS-102PE pan & tilt head (Environmental version) . . . . . . . . . . . . . . . . . . . . . AM-HS-102PE

HS-102P-IT pan & tilt head (Studio version with VR output) . . . . . . . . . . . . . . AM-HS-102-IT

HS-102P-ITE pan & tilt head (Environmental version with VR output). . . . . . AM-HS-102-ITE

Power Supplies

Power supply (modular) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AM-PS30-2

Power supply (rack mount). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-PS27-5R

Lens Drives (and cables)

Servo lens drive (generic) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-SLD-102OE

NLD for Fujinon digital lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-NLD-FED

NLD for Canon digital lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AM-NLD-CED

Video conference lens interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-VCL-IF

Adaptors and mounting brackets

Adapter plate for Vinten tripods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-VMA-105

Wall mount bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-WBKT-102

Ceiling/grid mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-CEIL-102

User replacement spares

Replacement desiccant capsule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AB-070169

Cables

Floor cable (power/data to HS-102P head) . . . . . . . . . . . . . . . . . . . . . . . . . AM-SP-CAB-XXX

Floor cable (power/data to HS-102PE head) . . . . . . . . . . . . . . . . . . . . . . .AM-HLE-CAB-XXX

Data cable (Multicontroller II to power supply) . . . . . . . . . . . . . . . . . . . . . . .AM-DD-CAB-XXX

Data cable (EPI controller to power supply) . . . . . . . . . . . . . . . . . . . . . . . .AM-LDD-CAB-XXX

Note: For all cables XXX = length in ft. or XXXm = length in m.
