FH/FHR-145 Pan and Tilt Head
Safety and Warnings
In most installations, the teleprompter (if installed) is mounted
onto the head and protrudes the furthest beyond the base of
the head. The footprint must take into account the overhang of
the teleprompter or other payload equipment as the head
moves about the pan axis.
Personnel need to be trained and aware of how far the head
and pedestal can move, the speeds involved and the need to
stay clear of robotic equipment at all times.
Warning Signs
Warning signs should be displayed prominently in the
workplace alerting personnel that robotic equipment is in use
and may move suddenly and without warning.
If personnel are working on robotic or associated equipment,
ensure a warning sign is placed at the controller (control panel)
to alert operators that work is being carried out.
Safety Notes for Operators
Operators must familiarise themselves with the working
footprint of the robotic head, including all associated equipment
(lens, zoom and focus controls, viewfinder, prompter, etc.) to
prevent inadvertent collisions or injury to personnel.
If personnel are too close to a head or pedestal that is about to
move, the operator should prevent the motion from starting or
stop the motion if it has started.
We strongly recommend that the operator verifies visually that
the active area is clear of hazards and personnel, both before
and during remote operation.
Intended Use
This product is designed for use within television studios to
support and balance a camera together with ancillary
equipment weighing up to 65 kg (145 lb). Camera operators can
remotely control the head pan and tilt axes, and the lens zoom
and focus using Vinten Radamec control systems.
Safe Working Environment
In normal operation, remote-controlled equipment can move
suddenly and without warning. Since audible warnings are not
suitable for use within the studio environment, it is
recommended that only trained personnel be allowed to work in
the active areas, where remote-controlled heads and pedestals
are located.
Personnel must be made aware of the potential hazards of
working in a robotic environment. To avoid personal injury,
personnel should always exercise caution when working in the
vicinity of robotic equipment. The forces are sufficient to cause
personal injury or injury to others, and therefore caution is
essential.
Safe Operating Zone
The safe operating zone for personnel is a minimum of 1 m
(3 ft) outside of the footprint of the pan and tilt head.
CAUTION! Risk of damage to equipment. Do not lift or
carry the head by the back cover.
Installation Guide
WARNING! The tilt lock MUST be engaged whenever
the head is lifted or transported and before installing or
adjusting the camera or payload.
3
