Figure 10, Controlling pan movements using a joystick, Figure 11 – Vinten Radamec Fusion FH-100 User Manual
Page 28: Controlling tilt movements using the joystick
15
Figure 10 Controlling pan movements using a joystick
Figure 11 Controlling tilt movements using the joystick
Zero Pan
Pan right
Pan left
Move joystick to the
left to pan left.
Move joystick to the
right to pan right.
Move joystick
backward to tilt the
camera upward.
Move joystick
forward to tilt the
camera downward.
