Page 13/15
8. Technical Data
AT200/3 rescue lifting device
Material winch
Galvanised steel with black epoxy
coating
Rope length
20 m, stainless steel with swivel
snap hook
Rope diameter 5 mm
Reduction ratio 4.5:1
Permissible max. load 136 kg / 1 Person
Breaking load of the sys-
tem
1.2 t
Average lift 10 cm / Revolution
Temperature resistance -36 °C to +60 °C
Weight, approx. 9.15 kg
We reserve the right to make technical changes in the scope of product improvements.
The rescue lifting device is equipped with a hold-back and a self-blo-
cking brake.
