Page 3/15
1. Important preliminary remarks
Solely the knowledge of and exact following of these operating instructions gua-
rantee proper and appropriate deployment, bring the greatest possible benefits
and meet the requirements contained within the scope of the Vetter guarantee.
Only instructed and qualified specialists are permitted to use the AT200/3 winch.
Every deployment/operation of the winch and its accessories assumes exact
knowledge of and compliance with these operating instructions.
Consider these operating instructions as a component of the product and retain
them during the product life cycle. If the product is passed on, give the operating
instructions to the subsequent user.
If the equipment will be sold in or passed on to another country, the reseller must
provide the instructions for the use, maintenance, regularly scheduled checks and
corrective maintenance in the language of the other country.
The rescue lifting device was certified in accordance with EN 1496 Class B.
2. Marking
Manufacturer PROTECTA International
Product description Rescue lifting device AT200
Type and Model Rescue lifting device AT200
Rope length 20 m
Serial no. e.g. 1238286
Month of manufacture e.g. 12
Year of manufacture e.g. 12
EN Standard/Year/Class EN 1496 Class B
Maximum utilization load 136 kg max
3. Product description
The AT200/3 rescue lifting device can be used together with the tripod, light ART
Lite Pod. The rescue lifting device is made of galvanized steel and has a black ep-
oxy coating. The rescue lifting device is equipped with a hold-back as well as with
a self-blocking brake. The stainless steel rope has a length of 20 m, a diameter of 5
mm and is equipped with a swivel snap hook.
The reduction ratio is 4.5:1. The mean lift is 10 cm / revolution.
There are two locking bolts on the device to attach the tripod to the rescue lifting
device.
