Vetter Lifting Bags 1.0 bar/14.5 psi
Page 13/15
7.
Technical data
Lifting bag 1.0 bar/14.5 psi
Type
1/23
1/13
1/9
1/6
DIN Nomination
LH 50 S
LH 30 S
LH 20 S
LH 10 S
Lifting power
to/US tons 11.3/12.45 6.5/7.15
4.5/4.95
3.0/3.3
Lifting power set
to/US tons 22.6/24.9
13.0/14.3
9.0/9.9
6.0/6.6
Lifting height, max.
cm/inch
122/48
78/31
72/28
55/22
Insertion height
(uninflated)
cm/inch
3/1.2
3/1.2
3/1.2
3/1.2
Diameter
cm/inch
120/47
91/36
76/30
61/24
Working pressure
bar/psi
1.0/14.5
1.0/14.5
1.0/14.5
1.0/14.5
Test pressure
bar/psi
1.5/21.75
1.5/21.75
1.5/21.75
1.5/21.75
Air requirement
at 1.0 bar
l/cu.ft.
3,023/107
1,038/37
667/24
328/12
Nominal content
l/cu.ft.
1,512/53
519/18
334/12
164/6
Inflation time, approx. sec.
191
62
42
20
Weight, approx.
kg/lbs
21/46
12/26
9/20
7/15
Weight (set), approx.
kg/lbs
55/121
37/82
31/68
25/55
Rescue Set
Lifting power
to/US
tons
12.1/13.3
Lifting height
cm/inch 65/26
Working
pressure
bar
1.0
psi
14.5
Test pressure
bar
1.5
psi
21.75
Air requirement
at 1.0 bar
l
2,164
cu.ft.
76.39
Nominal con-
tent
l
1,082
cu.ft.
38.19
Packaged size
cm
110 x 72 x 30
inch
43 x 28 x 12
Inflation time
sec.
164
Weight, approx. kg/lbs
25.0/55.1
All rights reserved for technical changes within the scope of product improvement.
We explicitly point out that changes made to the filling valve and the main pro-
ducts (e.g., modification of the original couplings/fitting nipple) plus operation
with third-party valves as well as third-party products obviates all liability and
warranty claims.
