Page 2/28
1. Important preliminary remarks
The test equipment for lifting bags is used for the correct and pro-
fessional execution of repetitive tests on:
9 Vetter lifting bags 0.5 bar
9 Vetter lifting bags 1 bar
9 Vetter mini lifting bags 8 bar
9 Vetter S.Tec lifting bags 10 bar
9 VEPRO pressure bags 0.5 bar
9 VEPRO pressure bags 1 bar
9 VEPRO mini lifting bags 8 bar
The 5 yearly pressure test according to GUV G 9102 for lifting bags
0.5 bar and 1bar is stipulated to be carried out by the manufactu-
rer.
The implementation of the visual test and functilon test according
to GUV G 9102 must only be carried out by a specialist according
to GUV G 9102. This assignment must normally be made in wri-
ting.
The inspector is responsible for carrying out his test assignment
and to abide by the regulations valid on the day of the test.
1.1 Inventory check
Pos.-Nr. Article No. Description
Test equipment
1700005302
Test equipment with
test pump 1700006803
1 1700005400 Blind coupling 0.5 bar (claw) X X
2 0350006500 Blind coupling 1 bar X X
3 0350006501 Blind coupling 1 bar, (quick action) X X
4 0350006300 Test manometer 0.5/1 bar X X
5 0800008000 Test manometer 8 bar X X
6 1000006600 Test manometer 10 bar X X
7 1700014300 Connector nipple/bayonet X
8 1700006501 Adapter, hasp, 3/4" X
9 1700010200 Test and measurement hose adapter X X
10 1600013401 Air supply hose, 10 m, X X
11 1700005501
Hand pump for water test with integ-
rated 10 l tank
X
12 1700005701 Inflation hose, 5 m, red, brass X
13 1700006101
Test and ventilation head with mano-
meter and 2 ball valves
X X
14 1000006300 S.Tec test adapter X X
15 1520002500 Bag, red, for transportation X
16 1700035500 Transport case X
