42VMC

GB - 2

Dimensions and weights - Minimum clearances (mm)

50 min

500 min

50 min

Dimensions and weights

Minimum clearances

Wall installation

Ceiling installation

Model

42VMC009

42VMC012

42VMC014

42VMC018

42VMC024

A

mm

850

850

1000

1000

1000

B

mm

540

540

600

600

600

kg

kg

15

16

18

18

20

Table I: Nominal data

Unit is not suitable for operation in laundry premises.

• For sizing of power supply wires and delay type fuses, refer to

the outdoor unit installation instructions.

POWER INPUT

Cooling only

Cooling

Heating

W

W

42VMC 009

25

42VMC 012

30

42VMC 014

55

42VMC 018

55

42VMC 024

80

Heat pump

42VMC 009

25

25

42VMC 012

30

30

42VMC 014

55

55

42VMC 018

55

55

42VMC 024

80

80

B

A

200

Ш 80

50

40
