User’s Manual TP-SW8
TYCON POWER SYSTEMS
11
Surge Protection on signal pairs
Signal
Operating Voltage Data 5V
Clamping Voltage Data 16.5V (@I PP =5A, t p =8/20µs, I/O pin to GND)
Peak Pulse Current 20A (tp=8/20µs)
Pin Protected 4 pin protected (signal pairs)
Max. Shut Capacitance
<3pF (VR = 0V, f = 1MHz, I/O pin to GND)
< 1.5 pF (VR = 0V, f = 1MHz, Between I/O pins)
IEC COMPATIBILITY (EN61000-4)
IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
IEC61000-4-4 (EFT) 40A (5/50ns)
IEC61000-4-5 (Lightning) 20A (8/20µs)
