800-472-7373
Audiovox 8900, 8915, Pantech PN-3200
Press ##27732726 and press END. Scroll down and select DEBUG. The signal strength is the
4th line down. (for example, Rx-79).
Audiovox 9100, 9155
When phone turns on, as soon as green light shuts off, press FCN (right arrow) and 00. It will ask
for FSC Code. Press 000000 (six zeroes). Press OK. Highlight DEBUG SCREEN and press FCN,
FCN. Signal strength is the top right number. On 2nd line, if the letter is upper case (for example,
“A”), then the phone is on the 1900MHz band. If lower case (“a”) it is on 800MHz. To exit test
mode, turn off phone.
Audiovox CDM-9900
Power the phone off and then back on again. Quickly Press MENU, 7, *, *. FSC Code is 000000
(six zeros). Press SELECT Key (middle button). Select DEBUG SCREEN. Select NORMAL.
Signal strength is on the second line after RX. You may have to dial a fake phone number (for
example, 555-1234) to get the Rx level to update. Press POWER OFF to exit.
Audiovox UTSTARCOM / HTC PPC- 6600, PPC-6700, XV -6700
From the phone screen, press ##33284# or ##33284 and press DIAL. The signal strength will be
after RSSI or RX level.
Blackberry
Press TOOLS, SETTINGS, STATUS or OPTIONS, STATUS. This feature is also available on
GSM models. The top line is the signal strength in –dBm.
HP 6315
Click on START. Select SETTINGS from the drop-down screen. Select SYSTEM tab at the
bottom of the screen. Scroll down to SELF TEST and select. Unmark all option boxes except
GSM/GPRS and click START. When the phone displays GPRS CONNECT NOW? select NO.
The 8th line down displays signal strength. Click REFRESH to update signal.
HTC EVO
Select phone application and key in ##33284# and press "call" to enter field trial mode. Select the
network that you want to see signal information for ("1X Engineering" = 1xRTT/2G, "EVDO
Engineering" = 3G, "WiMAX Engineering" = 4G). Look under "RX Power" for RSSI value. Press
the home button to exit.
HTC DASH / EXCALIBER / S620 (T-Mobile)
Enter *#*#364#*#* and your phone will enter test mode. Signal strength follows RSSI. This test
mode does not show –dB. Strong signal is 31 (approx-50 dBm), weak signal is 4 (approx-105
dBm), so the higher the number, the better the signal. Press END or Done to exit.
HTC Touch
##33284#
Kyocera 2035, 2135, 2235, 2255, 5135
Press 111111 (six ones). Select OPTIONS and press MENU (the upper right-hand star button) or
OK to select it. Select DEBUG and press MENU or OK. Enter field debug code, 111111 or
000000 (six ones or zeros) or 040793. Scroll down to DEBUG SCREEN and press MENU or OK.
Scroll to BASIC and press MENU or OK. The signal strength is the last number on the 1st line.
To exit the field test, select CLOSE and press MENU or OK.
