background image

4-3

LANVIEW LEDs

The functions of the two System Status LEDs, System Management Bus (SMB)
and the CPU, are listed in Table 4-1.

The functions of the INB receive LED are listed in Table 4-2.

The functions of the INB transmit LED are listed in Table 4-3.

Table 4-1. System Status LEDs (SMB and CPU)

LED Color

State

Description

Green

Functional

Fully operational.

Yellow (Flashing)

Crippled

Not fully operational (i.e., one bad port).

Yellow/Green

Booting

Blinks yellow and green while booting.

Red

Reset

Normal power-up reset.

Red (Flashing)

Failed

Fatal error has occurred.

Off

Power off

Module powered off.

Table 4-2. INB Receive LED

LED Color

State

Red

No link

Green (Flashing)

Link, Port Disabled

Green

Link, No activity

Yellow (Flashing)

Link, Port Enabled, Activity

Table 4-3. INB Transmit LED

LED Color

State

Red

No Link

Green (Flashing)

Link, Port Enabled, Activity

Yellow (Flashing)

Link, Bridge Standby

Off

Link, No activity
