Setting the module card dip switch, Setting the module card dip switch -4 – Cabletron Systems 9T428-16 User Manual
Page 18
Installation
2-4
Setting the Module Card DIP Switch
An eight position DIP switch is located just under the edge of the top module card
as shown in Figure 2-3. The functions of the switch are listed in Table 2-1.
Figure 2-3. Location of Module DIP Switch
1 2 3 4 5 6 7 8
