This is a simple operation but it is important to carry out correctly
as by not doing so several sewing problems could result.
- Start by raising the needle to its highest point (1), and also
raise the presser foot to release the tension discs. (2)
Note: For safety, it is strongly suggested you turn off the
power before threading.
- Draw thread from spool through the upper thread guide. (4)
- Thread tension module by leading thread down right channel
and up left channel (5). During this process it is helpful to hold
the thread between the spool and thread guide (4).
- At the top of this movement pass thread from right to left
through the slotted eye of the take-up lever and then
downwards again. (6)
- Pass thread behind the flat, horizontal thread guide. (7)
- Now take thread behind the needle clamp guide and then
down to the needle which should be threaded from front to
back. Pull about 6-8 inches of thread to the rear beyond the
needle eye. (8)
If your sewing machine is equipped with the factory installed
optional automatic needle threader, instructions for use can
be found on page 26.
Note:
- Place the thread and Spool pin felt (a) onto the spool pin. (3)
24
Threading the upper thread GB
6 7
8
3 4
1
2
3 4
6
5
7
8
5
a
