INSTALL ANCHOR HOOKS
1. INSTALL ANCHOR HOOKS
Back off FS-341 stopping screw at the bottom of the anchor bracket, slide in the anchor hook.
Tighten up FS-341, the screw is to prevent anchor hook from sliding out of the anchor bracket during
frame installation.
Slide the anchor hook
into anchor bracket
Tighten up FS-341
stopping screw
after anchor hook
installation
