377
Practical hints
Replacing bulbs
High beam flasher bulb
̈ Press ends of housing cover 1 tab to-
gether and remove cover.
̈ Press connector 2 downward.
̈ Remove connector 2 with the bulb.
̈ Insert the new bulb so that the base lo-
cates in the recess on the holder.
̈ From below, press connector 2 with
bulb upward onto the reflector.
̈ Align housing cover 1 and click into
place.
Front turn signal bulb
̈ Turn bulb socket 4 counterclockwise
and pull out.
̈ Gently push bulb into bulb socket 4,
turn counterclockwise and remove.
̈ Insert new bulb in bulb socket 4, push
in and twist clockwise.
̈ Reinsert bulb socket 4 in lamp and
twist clockwise.
Parking and standing lamp bulb
̈ Press ends of housing cover 1 tab to-
gether and remove cover.
̈ Pull out the bulb socket 3 with the
bulb.
̈ Pull the bulb out of the bulb socket 3.
̈ Insert a new bulb in the socket 3.
̈ Reinstall the bulb socket 3.
̈ Align housing cover 1 and click into
place.
Side marker lamp bulb
̈ Carefully slide lamp towards rear.
̈ Remove front end first.
̈ Twist bulb socket counterclockwise
and pull out.
̈ Pull bulb out of the bulb socket.
̈ Insert new bulb in socket.
̈ Reinstall bulb socket, push in and twist
clockwise.
̈ To reinstall lamp, set rear end in
bumper and let front end snap into
place.
Replacing bulbs for rear lamps
Before you start to replace a bulb for a
front lamp, do the following first:
̈ Turn the exterior lamp switch to M
( ୴ page 52).
̈ Open the trunk ( ୴ page 101).
