KTD-S0043-A Page 3 BIOS Update
KTA55/pITX Software Guide
2 BIOS Update
The update tools are available for three environments: DOS, EFI-Shell and Windows ® (Windows ® XP or Win-
dows ® 7 32/64 bit).
Note: If you update the Bios with the AFUDOS update tool please use the tool from the KTA55/pITX product
website. To verify that the correct version is used check that the displayed version info matches the fol-
lowing terms:
AMI Firmware Update Utility (APTIO) v?.??
Copyright (C) 2011 ... [or later]
Software conditions:
Operating System Tool Name Required Revision
AFUDOS.EXE (special version for EFI Bios) APTIO 2.37 or greater
DOS
BF.EXE 7.59 or greater
Windows ® (Console) BF.EXE 7.59 or greater
EFI-Shell KTA55UPD.EFI 1.0 or greater
2.1 AFUDOS (AMI)
Only the following combination of command line arguments has been tested and should be used for the
update process. The syntax of the DOS update tool is:
AFUDOS /X /P /B /N
/X = do not check ROM ID
/P = program main Bios image
/B = program boot block
/N = overwrite NVRAM (setup settings)
2.2 KTA55UPD (Kontron)
This program is a EFI tool and works only in a EFI environment. You can use a FAT16/FAT32 formatted
device (e.g. a USB key). Copy the update tool and the Bios to the root directory. Then boot the KTA55 board
and press the
F7 key during the boot process (calls the boot menu). Choose the entry ' UEFI: Built-in EFI
Shell ' and press Enter. After the Shell is active type ' fs0: ' and press Enter if you use a USB key - for other
boot devices this identifier can be different. Now you can use KTA55UPD.EFI with the following syntax:
KTA55UPD
