CY25566
Document #: 38-07429 Rev. *B
Page 7 of 9
Absolute Maximum Ratings
[1, 2]
Supply Voltage (V
DD
: .......................................................+6V
Operating Temperature: ...................................... 0°C to 70°C
Storage Temperature .................................. –65°C to +150°C
Table 4. DC Electrical Characteristics V
DD
= 3.3V, Temp. = 25°C, unless otherwise noted
Parameter
Description
Conditions
Min.
Typ.
Max.
Unit
V
DD
Power Supply Range
±10%
2.97
3.3
3.63
V
V
INH
Input High Voltage
S0 and S1 only.
0.85V
DD
V
DD
V
DD
V
V
INM
Input Middle Voltage
S0 and S1 only.
0.40V
DD
0.50V
DD
0.60V
DD
V
V
INL
Input Low Voltage
S0 and S1 only.
0.0
0.0
0.15V
DD
V
V
OH1
Output High Voltage
I
OH
= 6 ma, SSCLKa
2.4
V
V
OH2
Output High Voltage
I
OH
= 20 ma, SSCLKb
2.0
V
V
OL1
Output Low Voltage
I
OH
= 6 ma, SSCLKa
0.4
V
V
OL2
Output Low Voltage
I
OH
= 20 ma, SSCLKb
1.2
V
C
in1
Input Capacitance
Xin/CLK (Pin 1)
3
4
5
pF
C
in2
Input Capacitance
Xout (Pin 8)
6
8
10
pF
C
in2
Input Capacitance
All input pins except 1.
3
4
5
pF
I
DD1
Power Supply Current
FIN = 40 MHz,15 pF@all outputs
27
32
mA
I
DD1
Power Supply Current
FIN = 40 MHz, No Load
21
28
mA
I
DD2
Power Supply Current
FIN = 165 MHz,15 pF@all outputs
68
80
mA
I
DD2
Power Supply Current
FIN = 165 MHz, No Load
48
60
mA
Table 5. Electrical Timing Characteristics V
DD
= 3.3V, T = 25°C and C
L
= 15 pF, unless otherwise noted. Rise/Fall @ 0.4–2.4V,
Parameter
Description
Conditions
Min.
Typ.
Max
Unit
I
CLKFR
Input Clock Frequency Range Non-crystal, 3.0V Pk–Pk ext. source
25
200
MHz
t
RISE(a)
Clock Rise Time
SSCLK1a or SSCLK1b, Freq = 100 MHz
1.0
1.3
1.6
ns
t
FALL(a)
Clock Fall Time
SSCLK1a or SSCLK1b, Freq = 100 MHz
1.0
1.3
1.6
ns
t
RISE(a+b)
Clock Rise Time
SSCLK1(a+b), CL = 33 pF, 100 MHz
1.2
1.5
1.8
ns
t
FALL(a+b)
Clock Fall Time
SSCLK1(a+b), CL = 33 pF, 100 MHz
1.2
1.5
1.8
ns
t
RISE(a+b)
Clock Rise Time
SSCLK1(a+b), CL = 33 pF, 200 MHz
1.1
1.4
1.7
ns
t
FALL(a+b)
Clock Fall Time
SSCLK1(a+b), CL = 33 pF, 200 MHz
1.1
1.4
1.7
ns
t
RISE(REF)
Clock Rise Time
REFOUT, Pin 3, CL = 15 pF, 50 MHz
1.0
1.3
1.6
ns
t
FALL(REF)
Clock Fall Time
REFOUT, Pin 3, CL = 15 pF, 50 MHz
1.0
1.3
1.6
ns
D
TYin
Input Clock Duty Cycle
XIN/CLK (Pin)
30
50
70
%
D
TYout
Output Clock Duty Cycle
SSCLK1a/b (Pin 8 and 9)
45
50
55
%
C
CJ1
Cycle-to-Cycle Jitter
F = 100 MHz, SSCLK1a/b CL = 33 pF
300
400
ps
C
CJ2
Cycle-to-Cycle Jitter
F = 200 MHz, SSCLK1a/b CL = 33 pF
500
600
ps
REFOUT
Refout Frequency Range
CL = 15 pF
25
108
MHz
Note:
1.
Operation at any Absolute Maximum Rating is not implied.
2.
Single Power Supply: The voltage on any input or I/O pin cannot exceed the power pin during power-up.
