CPCI Backplane PD06: CP3-BP8-P47-RIO
RID 24229 PD06, Rev. 01 © 2002 PEP Modular Computers GmbH Page 3
1. CPCI BackplaneIntroduction
The specific product description provided with this product documentation is part of the PEP’s
CPCI Backplane manual. For further information, in particular regarding general details as well
as safety and warranty statements, refer to the CPCI Backplane Manual, ID 24229.
2. CP3-BP8-P47-RIO Positronic-type Backplane
The main features of the 3U, 8-slot, 47-pin Positronic-type backplane CP3-BP8-P47-RIO,
which is designed for rear I/O applications, are described in the following table:
Table 1: Distinctive Features of Backplane CP3-BP8-P47-RIO
Feature Specification
Form Factor 3U
Size 202.2*128.7 mm
Number of Slots 8
Bus Resolution 32 bits: slots 1 to 8
Bus Frequency 33MHz: slots 1 to 8
Rear I/O Connectivity P2 on slots 1 to 8
Hot-Swap Capability Yes
Power Supply Connector 47-pin Positronic PCIH47
Redundant Power Supply Optional
Flexible Grounding Option Yes
Fan Connector Yes
MSD Connector Yes
PS-ON Connector Yes (INH#)
Reset Function Connector Yes
IPMB Extension Connector Yes (IPMB0)
System MON-CTRL Connector Yes
