PD06: CP3-BP8-P47-RIO CPCI Backplane
Page 10 © 2002 PEP Modular Computers GmbH RID 24229 PD06, Rev. 01
5.5 System Management Connector JP19
One five-contact male system management bus (IPMB0) connector, JP19, is provided for
external interfacing to this bus. As this backplane has the RIO connector rP2 installed at the
system controller slot, pin 5, SMB_ALERT, is not connected on JP19.
Figure 7: Orientation and Pinout of the CP3-BP8-P47-RIO IMPB0 Connector JP19
1
5
Table 8: Pinout of CP3-BP8-P47-
RIO IMPB0 Connector JP19
Pin Function
1 IMPB0_SCL
2 GND
3 IMPB0_SDA
4 IMPB0_PWR
5 not connected
