CPCI Power Supply PD14: CP3-SVE-P200DC-24V
RID 24139 PD14, Rev.02
1. Introduction
The specific product description provided with this product documentation is part of the PEP’s
CPCI Power Supply manual. For further information, in particular regarding general details as
well as safety and warranty statements, refer to the CPCI Power Supply Manual, ID 24139.
2. 200W P-Type Power Supply Unit
The main features of the 3U P-type, 18V ... 36V DC input, 200W output DC/DC power supply
unit CP3-SVE-P200DC-24V are described in the following table:
Table 1: Distinctive Features of Power Supply Unit CP3-SVE-P200DC-24V
FEATURE SPECIFICATION
Form Factor 3U
Front Panel Size 40.34 mm x 128.6 mm
Mechanics 19” rack
Plug-In Compatibility Yes
Power Supply Connector Positronic 47-pin connector
Input Voltage 18 … 36 V DC
Voltage Switching Widerange
Output Power 200W with 250 LFM forced-air cooling (ca. 1.3 m/s)
Output Voltages / Currents
V
1
= + 5V at 25 A
V
2
= + 3.3 V at 36 A
V
3
= + 12 V at 3 A
V
4
= - 12 V at 0.5 A
Cooling 250 LFM forced-air cooling (ca. 1.3 m/s)
Redundant Supply Capability Always
Status Indication LED’s for input good and power fail
Special Feature(s) None
