SMARC-sXBTi / Product Specification
3.2 Functional Specification
Processor
The 32nm Intel® ATOM™ / Celeron® (BayTrail-I SOC (Valleyview)) CPU family supports:
» Intel® 64
» Enhanced Intel SpeedStep® Technology
» Thermal Monitoring Technologies
» Execute Disable Bit
» Virtualization Technology VT-x
» 2 Display Pipes for dual independent displays
CPU specifications
Intel® Atom™ Atom™ Atom™ Atom™ Atom™
- E3845 E3827 E3826 E3825 E3815
Stepping B3/D0 B3/D0 B3/D0 B3/D0 B3/D0
# of Cores 4 2 2 2 1
# of Threads 4 2 2 2 1
CPU Nominal frequency 1.91GHz 1.75GHz 1.46GHz 1.33GHz 1.46GHz
CPU Burst frequency - - - - -
LFM/LPM Frequency 533MHz 533MHz 533MHz 533MHz 533MHz
Tjunction -40 to 110°C -40 to 110°C -40 to 110°C -40 to 110°C -40 to 110°C
Thermal Design Power (TDP) 10W 8W 7W 6W 5W
SDP - - - - -
Smart Cache 2x1MB 2x512kB 2x512kB 2x512kB 512kB
Memory Type DDR3L-1333 DDR3L-1333 DDR3L-1066 DDR3L-1066 DDR3L-1066
Max Memory Size 8GB 8GB 8GB 8GB 8GB
ECC Memory(optional) Yes Yes Yes Yes Yes
Graphics Model Intel HD® Intel HD® Intel HD® Intel HD® Intel HD®
GFX Base Frequency 542MHz 542MHz 533MHz 533MHz 400MHz
GFX Max Dynamic Frequ. 792MHz 792MHz 667MHz - -
GFX Technology GT1 4EU GT1 4EU GT1 4EU GT1 4EU GT1 4EU
AEC Q100 automtovie Qual. Yes Yes Yes Yes Yes
SDIO Yes Yes Yes Yes Yes
eMMC Yes Yes Yes Yes Yes
AES-NI (optional) Yes Yes Yes Yes Yes
Memory
Sockets memory down
Memory Type DDR3L-1066/1333
Maximum Size 2 - 4GB (ECC optional)
Technology Single Channel (64bit)
