COMe-cHL6 / Pinout List
D65
PEG_TX4+
PCIexpress Graphics Transmit + (4)
DP-O
-
not available on cHL6 module
D66
PEG_TX4-
PCIexpress Graphics Transmit - (4)
DP-O
-
not available on cHL6 module
D67
GND
Power Ground
PWR
-
-
D68
PEG_TX5+
PCIexpress Graphics Transmit + (5)
DP-O
-
not available on cHL6 module
D69
PEG_TX5-
PCIexpress Graphics Transmit - (5)
DP-O
-
not available on cHL6 module
D70
GND
Power Ground
PWR
-
-
D71
PEG_TX6+
PCIexpress Graphics Transmit + (6)
DP-O
-
not available on cHL6 module
D72
PEG_TX6-
PCIexpress Graphics Transmit - (6)
DP-O
-
not available on cHL6 module
D73
GND
Power Ground
PWR
-
-
D74
PEG_TX7+
PCIexpress Graphics Transmit + (7)
DP-O
-
not available on cHL6 module
D75
PEG_TX7-
PCIexpress Graphics Transmit - (7)
DP-O
-
not available on cHL6 module
D76
GND
Power Ground
PWR
-
-
D77
RSVD
n.c.
Nc
-
-
D78
PEG_TX8+
PCIexpress Graphics Transmit + (8)
DP-O
-
not available on cHL6 module
D79
PEG_TX8-
PCIexpress Graphics Transmit - (8)
DP-O
-
not available on cHL6 module
D80
GND
Power Ground
PWR
-
-
D81
PEG_TX9+
PCIexpress Graphics Transmit + (9)
DP-O
-
not available on cHL6 module
D82
PEG_TX9-
PCIexpress Graphics Transmit - (9)
DP-O
-
not available on cHL6 module
D83
RSVD
n.c.
Nc
-
-
D84
GND
Power Ground
PWR
-
-
D85
PEG_TX10+
PCIexpress Graphics Transmit + (10) DP-O
-
not available on cHL6 module
D86
PEG_TX10-
PCIexpress Graphics Transmit - (10)
DP-O
-
not available on cHL6 module
D87
GND
Power Ground
PWR
-
-
D88
PEG_TX11+
PCIexpress Graphics Transmit + (11) DP-O
-
not available on cHL6 module
D89
PEG_TX11-
PCIexpress Graphics Transmit - (11)
DP-O
-
not available on cHL6 module
D90
GND
Power Ground
PWR
-
-
D91
PEG_TX12+
PCIexpress Graphics Transmit + (12) DP-O
-
not available on cHL6 module
D92
PEG_TX12-
PCIexpress Graphics Transmit - (12) DP-O
-
not available on cHL6 module
D93
GND
Power Ground
PWR
-
-
D94
PEG_TX13+
PCIexpress Graphics Transmit + (13) DP-O
-
not available on cHL6 module
D95
PEG_TX13-
PCIexpress Graphics Transmit - (13) DP-O
-
not available on cHL6 module
D96
GND
Power Ground
PWR
-
-
D97
RSVD
n.c.
Nc
-
-
D98
PEG_TX14+
PCIexpress Graphics Transmit + (14) DP-O
-
not available on cHL6 module
D99
PEG_TX14-
PCIexpress Graphics Transmit - (14)
DP-O
-
not available on cHL6 module
D100 GND
Power Ground
PWR
-
-
D101 PEG_TX15+
PCIexpress Graphics Transmit + (15) DP-O
-
not available on cHL6 module
D102 PEG_TX15-
PCIexpress Graphics Transmit - (15) DP-O
-
not available on cHL6 module
D103 GND
Power Ground
PWR
-
-
D104 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
D105 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
D106 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
D107 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
D108 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
D109 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
D110 GND
Power Ground
PWR
-
-
The termination resistors in these tables are already mounted on the module. Refer to the
design guide for information about additional termination resistors.
