COMe-cHL6 / System Resources
5.4 Peripheral Component Interconnect (PCI) Devices
All devices follow the Peripheral Component Interconnect 2.3 (PCI 2.3) respectivily the PCI Express Base 1.0a
specification. The BIOS and OS control memory and I/O resources. Please see the PCI 2.3 specification for details.
PCI Device B:D:F PCI IRQ Interface Comment
Host Bridge 0:0:0 LNK A internal Chipset
Video Controller 0:2:0 LNK A internal Chipset
SA Audio 0:3:0 LNK A internal Chipset
XHCI 0:20:0 LNK A internal Chipset
ME 0:22:0 LNK A internal Chipset
GbE 0:25:0 LNK E internal Chipset
EHCI2 0:26:0 LNK A internal Chipset
PCH HDA 0:27:0 LNK G PCIe Chipset
PCIe Port 0 0:28:0 LNK A internal Chipset
PCIe Port 0 Slot - A/B/C/D PCIe Port 0
PCIe Port 1 0:28:1 LNK A internal Chipset
PCIe Port 1 Slot - B/C/D/A PCIe Port 1
PCIe Port 2 0:28:2 LNK A internal Chipset
PCIe Port 2 Slot - C/D/A/B PCIe Port 2
PCIe Port 3 0:28:3 LNK A internal Chipset
PCIe Port 3 Slot - D/A/B/A PCIe Port 3
PCIe Port 4 0:28:4 LNK A internal Chipset
PCIe Port 4 Slot - A/B/C/D PCIe Port 4
EHCI1 0:29:0 LNK H internal Chipset
LPC Bridge 0:31:0 LNK F internal Chipset
SATA 0:31:2 LNK D internal Chipset
SMBus 0:31:3 LNK C internal Chipset
5.5 Internal I2C Bus
8-bit Address 7-bit Address Used For Available Comment
58h 0x2C S5 Eco No S5 Eco Resistor
A0h 0x50 JILI-EEPROM No external LVDS EEPROM for JILI
Data
C0h 0x60 LVDS bridge No DP to LVDS Bridge
5.6 External I2C Bus
8-bit Address 7-bit Address Used For Available Comment
A0h 0x50 JIDA-EEPROM No Module EEPROM
AEh 0x57 FRU-EEPROM No Recommended for Baseboard
EEPROM
