COMe-cHL6 / Pinout List
A65
PCIE_TX1-
PCI Express lane 1 - Transmit
DP-O
-
-
A66
GND
Power Ground
PWR
-
-
A67
GPI2
EXT_GPI2 / General Purpose Input 2
I-3.3
PU 10k 3.3V (S0)
-
A68
PCIE_TX0+
PCI Express lane 0 + Transmit
DP-O
-
-
A69
PCIE_TX0-
PCI Express lane 0 - Transmit
DP-O
-
-
A70
GND
Power Ground
PWR
-
-
A71
LVDS_A0+/eDP_TX2+
LVDS_A_DATA0_P / eDP_TX2_P
DP-O
-
-
A72
LVDS_A0-/eDP_TX2-
LVDS_A_DATA0_N / eDP_TX2_N
DP-O
-
-
A73
LVDS_A1+/eDP_TX1+
LVDS_A_DATA1_P / eDP_TX1_P
DP-O
-
-
A74
LVDS_A1-/eDP_TX1-
LVDS_A_DATA1_N / eDP_TX1_N
DP-O
-
-
A75
LVDS_A2+/eDP_TX0+
LVDS_A_DATA2_P / eDP_TX0_P
DP-O
-
-
A76
LVDS_A2-/eDP_TX0-
LVDS_A_DATA2_N / eDP_TX0_N
DP-O
-
-
A77
LVDS/eDP_VDD_EN
LVDS/eDP_VDD_EN / LVDS/eDP Panel Power
Control
O-3.3
PD 100k
-
A78
LVDS_A3+
LVDS_A_DATA3_P / LVDS Channel A Data3+
DP-O
-
-
A79
LVDS_A3-
LVDS_A_DATA3_N / LVDS Channel A Data3-
DP-O
-
-
A80
GND
Power Ground
PWR
-
-
A81
LVDS_A_CK+/eDP_TX3+
LVDS_A_CLK_P / eDP_TX3_P / LVDS Ch A Clock+ DP-O
-
-
A82
LVDS_A_CK-/eDP_TX3-
LVDS_A_CLK_N / eDP_TX3_N / LVDS Ch A Clock- DP-O
-
-
A83
LVDS_I2C_CK/eDP_AUX+
LVDS_DDC_CLK / eDP_AUX_P / LVDS I2C Clock
I/O-3.3
PU 2k21 3.3V (S0) -
A84
LVDS_I2C_DAT/eDP_AUX- LVDS_DDC_DATA / eDP_AUX_N / LVDS I2C Data
I/O-3.3
PU 2k21 3.3V (S0) -
A85
GPI3
EXT_GPI3 / General Purpose Input 3
I-3.3
PU 10k 3.3V (S0)
strapping function (if pulled low till release of
CB_RESET#, LVDS is disabled to enable eDP)
A86
RSVD
n.c.
Nc
-
-
A87
RSVD/eDP_HPD
n.c. / eDP Hot Plug Detect
DP-0
-
-
A88
PCIE_CLK_REF+
CLK_PCIE_REF_P / PCIE Reference Clock
DP-O
-
-
A89
PCIE_CLK_REF-
CLK_PCIE_REF_N / PCIE Reference Clock
DP-O
-
-
A90
GND
Power Ground
PWR
-
-
A91
SPI_POWER
V3.3_SPI_POWER
O-3.3
-
power supply pin for external SPI flash
A92
SPI_MISO
SPI_SO / SPI slave output
I-3.3
-
int. PU 20k in PCH
A93
GPO0
EXT_GPO0 / General Purpose Output 0
O-3.3
PD 10k
-
A94
SPI_CLK
SPI_CLK / SPI clock
O-3.3
-
-
A95
SPI_MOSI
SPI_SI / SPI slave input
O-3.3
-
int. PD 20k in PCH
A96
TPM_PP
TPM Physical Presence
I-3.3
PD 100k
-
A97
TYPE10#
n.c. for type 2 module
Nc
-
-
A98
SER0_TX
serial port 0 TXD
O-3.3
-
-
A99
SER0_RX
serial port 0 RXD
I-3.3
PU 47K 3.3V (S0)
-
A100 GND
Power Ground
PWR
-
-
A101 SER1_TX
serial port 1 TXD
O-3.3
-
-
A102 SER1_RX
serial port 1 RXD
I-3.3
PU 47K 3.3V (S0)
-
A103 LID#
LID switch input
I-3.3
PU 10K 3.3V (S5)
-
A104 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
A105 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
A106 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
A107 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
A108 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
A109 VCC_12V
main input voltage (8.5-20V)
PWR 8.5-20V -
-
A110 GND
Power Ground
PWR
-
-
