COMe-cHL6 / Product Specification
Misc Interfaces and Features
Supported BIOS Size/Type
16MB SPI
Audio
HD Audio + DisplayPort dual stream
Onboard Hardware Monitor
Nuvoton NCT7802Y
Trusted Platform Module
Atmel AT97SC3204
Miscellaneous
2x UART / PWM FAN / optional eDP
Kontron Features
External I2C Bus
Fast I2C, MultiMaster capable
Smart Battery (M.A.R.S.) support
YES
Embedded API
KEAPI3
Custom BIOS Settings / Flash Backup
YES
Watchdog support
Dual Staged
Additional features
» All solid capacitors (POSCAP). No tantalum capacitors used.
» Optimized RTC Battery monitoring to secure highest longevity
» Real fast I2C with transfer rates up to 40kB/s.
» Discharge logic on all onboard voltages for highest reliability
Power Features
Singly Supply Support
YES
Supply Voltage
8.5V - 20V
ACPI
ACPI 4.0
S-States
S0, S3, S4, S5
S5 Eco Mode
YES
Misc Power Management
cTDP @ i7/i5/i3
Power Consumption and Performance
Full Load Power Consumption
14 - 30W
Kontron Performance Index
41000 - 65269
Kontron Performance/Watt
2009 - 2997
*Measured Values. Please note the maximum Power Consumption with activated Turbo Mode in chapter Turbo 2.0
Detailed Power Consumption measurements in all states and benchmarks for CPU, Graphics
and Memory performance are available in Application Note
at
17
