12 onboard fan connector, Onboard fan connector – Kontron COMe-mBT10 User Manual
Page 27
COMe-mBT10 / Product Specification
3.12 Onboard Fan Connector
Specification
» Part number (Molex) J3: 53261-0371
» Mates with: 51021-0300
» Crimp terminals: 50079-8100
Pin assignment
» Pin1: Tacho, Pin2: VCC, Pin3: GND
Electrical characteristic
Module Input Voltage
4.75 - 13V
>13
FAN Output Voltage
4.75 - 13V
13V
Max. FAN Output Current
350mA
150mA
27
