COM Express® Eval Carrier Type 6
7
3 Specification
3.1 Functional Specification
» COM Express® baseboard compatible to Type 6 pin-out based modules
» ATX EPS (20pin + 4pin) power connector
» 1x PEG x16 slot
» 1x PCI Express x4 slots
» 2x PCI Express x1 slots
» 4 x SATA
» 1x LVDS/JILI FFC 40 connector
» 3x DDI (2x Display Port, 1x PCIe x16)
» 1x PEG x16
» 1x VGA
» 1x 1x 10/100/1000 MBit LAN; RJ45 connector
» 2x USB 2.0
» 4x USB 3.0
» 1x USB on Express Card
» 1x USB on miniPCI Expres
» LPC Firmware Hub and SPI Flash support for external BIOS
» Kontron feature connector
» Front panel connectors (HDD Act., Reset and Power Switch)
» Status LED
» MicroSD Connector
» GPIO pin header for module GPIO and Nuvotron LPC-I/O GPIO
» 4 digit Port 80/81 POST code display with POST code control
» LID and SLEEP support
» Power Control functions (Power Button override, module single supply,
power consumption measurements)
» Realtek ALC886 HD-Audio
» Audio Jack 3 in 1
» PWM FAN and Hardware Monitor connectors (FAN/Voltage)
