13 cpld & post-code display, Cpld & post-code display – Kontron COMe Eval Carrier T6 User Manual
Page 36
COM Express® Eval Carrier Type 6
35
5.13
CPLD & POST-Code Display
Power Management control, 4 digits LPC/PCI Port 80/81 Post Code and
additional GPIOs are implemented in onboard Altera CPLD (U28).
Port 80/81 POST Code
The 7-segment display D63/D64 for Port 81 and D61/62 for Port 80 shows BIOS
status codes during boot-up process.
