COM Express® Eval Carrier Type 6
42
9 LEC Indicators
For user convenience, Kontron has included some LED indicators along the side
of the board design. These are noted in the chart below and circled in the
picture of the carrier board included at the end of this section.
Resister LED Function
R120 D29 Hdd Activity
R124 D30 Module Rev 2
R125 D31 Module Type 1
R126 D32 Module Type 2
R129 D33 Module Type 3
R130 D34 Module Type 4
R132 D35 Module Type 5
R149 D36 Module Type 6
R174 D37 Module Type 10
R191 D38 Watchdog
R203 D39 THRMTRIP#
R211 D40 SUS_S5#
R213 D42 SUS_S4#
R216 D43 SUS_S3#
R222 D44 Sus_state#
R229 D45 V3.3_S5
R235 D46 V5.0_S5
R240 D47 V1.5_S0
R243 D48 V3.3_S0
R250 D49 V5.0_S0
R252 D50 V12_AUX_S0
R255 D51 V12_S0
R262 D54 V-12_S0
