COMe-bSC2 / Product Specification
PEG Configuration
The x16 PCI Express Graphics Port (PEG) is compatible to standard PCI Express devices like Ethernet or RAID controllers.
The COMe-bSC2 supports following PEG Port configuration when used as PCI Express Interface:
» 1Ч16
» 1Ч8
» 1Ч4
» 1Ч2
» 1Ч1
The internal PCI Express controller can be re-configured to support up to 3 PCIe ports. The following port configurations
are available via hardware strap options (customized article):
» 2×8 (lanes #0-7 + #8-15)
» 1Ч8 + 2Ч4 (lanes #0-7 + #8-11 + #12-15)
Storage
onboard SSD -
SD Card support -
IDE Interface JMB368 PCIe2PATA
Serial-ATA 2x SATA 6Gb/s, 2x SATA 3Gb/s
SATA AHCI NCQ, HotPlug, Staggered Spinup, eSATA, PortMultiplier
SATA RAID 0, 1, 5, 10, MATRIX (QM67 only)
If SATA AHCI or RAID is disabled in setup, the SATA Interface only supports 3Gb/s transfer
rate and Staggered Spin-Up. To configure a RAID enable RAID support in BIOS Chipset/SATA
settings, connect at least two hard drives and enter the RAID Option ROM by pressing
'CTRL'+'I'
Connectivity
USB 2.0 up to 8x USB 2.0
USB 3.0 -
USB Client -
PCI PEX8112 PCIe2PCI
PCI External Masters 4
PCI Express 5x PCIe x1 Gen2
Max PCI Express 6x PCIe without PCIe2PATA Bridge
PCI Express x2/x4 configuration YES (Softstrap option)
Ethernet 10/100/1000 Mbit
Ethernet controller Intel® 82579LM (Lewisville)
