AM4022 uEFI BIOS Main Setup
ID 1052-1333, Rev. 1.0 Page 19
2.7.1.2.1.7 VT-UTF8 Combo Key Support
Use this setting to enable or disable VT-UTF8 Combination Key Support for ANSI/ VT100 ter-
minals.
Default setting: Enabled
2.7.1.2.1.8 Recorder Mode
Use this setting to specify whether display formatting characters are to be transmitted along
with data or if only data is to be transmitted.
Default setting: Disabled
2.7.1.2.1.9 Resolution 100x31
Default setting: Enabled
2.7.1.2.1.10 Legacy OS Redirection
Default setting: 80x24
2.7.2 Serial Port for Out-of-Band Management/Windows Emergency
Management Services (EMS)
The following functions control the presence and content of the ACPI serial port redirection ta-
ble (SPCR). This table is mainly used by the Windows server variants to provide Windows
Emergency Management Services (EMS). This functionality is totally independent from serial
redirection of other console output.
SETTING DESCRIPTION
Disabled Use this setting the disable combination key support.
Enabled Use this setting the enable combination key support.
SETTING DESCRIPTION
Disabled Use this setting to specify normal terminal operation.
Enabled Use this setting to specify that only text will be sent. Use this to capture terminal data.
SETTING DESCRIPTION
Disabled Use this setting the disable extended terminal resolution.
Enabled Use this setting the enable extended terminal resolution.
SETTING DESCRIPTION
80x24 Use one of these settings to select the number of rows and columns for legacy OS redirec-
tion.
80x25
