AM4140 U-Boot Bootloader U-Boot Usage
ID 1052-0281, Rev. 1.0 Page 37
P R E L I M I N A R Y
6.2.2.2 sconf select
To change the setting, invoke the “sconf select” command.
Example:
6.2.2.3 sconf set
The setting of the chosen base configuration can be changed via the “sconf set” command. If
the “sconf set” command is invoked without parameters, all changeable options are shown. In
the following example, first, all possible settings are shown, and then the SerDes port 1 is
changed from rear to the front Ethernet connector J2 (GbE B). In certain “sconf base select”
configurations the ETH front PHY is not available anymore. In such cases it is possible to
switch the AMC SerDes port 1 as copper port to the front panel connector J2 (GbE B).
=> sconf select 5
New base configuration 5
=>
=> sconf set
Board’s Port Configuration:
Option / Setting | Value # command, option
---------------------------------------------------------------
Port 1 : rear # sconf set port1
SRIO Sys.Size : small # sconf set srio
SRIO mode : agent # sconf set srio
AMC Port Activation / Forced settings (ignoring E-Keying):
Option / Setting | Value # command, option
---------------------------------------------------------------
Port 4 : auto # sconf set port4
Port 8 : auto # sconf set port8
FCLKA : auto # sconf set fclk
=>
=> sconf set port1 front
=>
