U-Boot Usage AM4140 U-Boot Bootloader
Page 28 ID 1052-0281, Rev. 1.0
P R E L I M I N A R Y
USAGE: Display available configurations
COMMAND / RESPONSE:
=> sconf info
List of available base configurations:
**< >** Stored base configuration
--[ ]-- ‘New’base configuration (work in progress)
========+-=============================================
Base | Port 0 Port 1 Port 4 Port 8
Config | ..7 ..11
========+-=============================================
|
**[ 0]**| GbE GbE SRIO @3.125 SRIO @3.125
|
< 1> | GbE GbE SRIO @3.125 GbE 4x1
|
< 2> | GbE GbE SRIO @3.125 PCIE [Gen.2]
|
< 3> | GbE [GbE] SRIO @2.5 SRIO @2.5
|
< 4> | GbE [GbE] SRIO @2.5 XAUI
|
< 5> | GbE [GbE] SRIO @2.5 PCIE [Gen.2]
|
< 6> | GbE [GbE] PCIE [Gen.2] PCIE [Gen.2]
|
< 7> | GbE [GbE] PCIE [Gen.2] XAUI
|
Note: [GbE] indicates that used DTSEC1 can be redirected to front
panel connector J2(GbE B). This may be required for board
configurations which otherwise do not provide front ethernet
connectivity.
Board’s Port Configuration:
Option / Setting | Value # command, option
--------------------------------------------------------------
SRIO Sys.Size : small # sconf set srio
SRIO mode : agent # sconf set srio
AMC Port Activation / Forced settings (ignoring E-Keying):
Option / Setting | Value # command, option
-------------------------------------------------------------
Port 4 : auto # sconf set port4 | disable | enable>
Port 8 : auto # sconf set port8 | disable | enable>
=>
sconf (continued)
