A-2 AM453x
www.kontron.com
A.2 SATA (J3)
A.3 RJ45 Serial Port Connector(J5)
B37 GND B79 GND B122 GND B165 TCLK
B38 RxD3+ B80 CLKC+(N.C.) B123 RxD14-(N.C.) B166 TMS
B39 RxD3- B81 CLKC-(N.C.) B124 RxD14+(N.C.) B167 TRST#
B40 GND B82 GND B125 GND B168 TDO
B41 ENABLE# B83 PS0# B126 TxD14-(N.C.) B169 TDI
B42 12V B84 12V B127 TxD14+(N.C.) B170 GND
B85 GND B128 GND
Pin Signal Pin Signal
S1 GND P1 3.3V
S2 PortA_TX+ P2 3.3V
S3 PortA_TX- P3 3.3V
S4 GND P4 GND
S5 PortA_RX- P5 GND
S6 PortA_RX+ P6 GND
S7 GND P7 5V
S8 N.C. P8 5V
S9 N.C. P9 5V
S10 N.C. P10 GND
S11 N.C. P11 Ready LED
S12 N.C. P12 GND
S13 N.C. P13 N.C.
S14 N.C. P14 N.C.
P15 N.C.
Pin Signal Pin Signal
1 GND 5 3.3V
2 PortA_TX+ 6 3.3V
3 PortA_TX- 7 3.3V
4 GND 8 GND
Pin Signal Pin Signal Pin Signal Pin Signal
