1.3 Board Specifications
Table 1-1: Board Specifications
* Designed to meet or exceed
1.4 Hot-Swap Capability
The AM453x supports Full Hot Swap capability as per PICMG3.0 R2.0. It can be removed from or installed in
the system while it is on (without powering-down the system). Please refer to the PICMG3.0 R2.0
specification for additional details. The OS must support drive hot swap.
Features Description
Compliancy
• AMC.0 R2.0 base Specifications
• AMC.2 R1.0 Ethernet Specifications
Supported HDD
• SATA I and SATA II
• 1.8” and 2.5” SSD
Connector • Serial RJ45 connector
IPMI Features
• Management Controller compliant to PICMG 3.0, AMC.0 R2.0 and IPMI v2.0.
• Management Controller is run time field reprogrammable without payload impact.
• Robust fail safe reprogramming implementation (which includes two firmware images) that
could perform automatic or manual rollback if a problem occurs during critical reprogramming
phase.
• Remote upgrade capability from all IPMI interfaces (via IPMB).
• Management Controller self test which can detect failure under its code integrity and trig an
automatic rollback.
Supervisory
• Hardware system monitor through IPMI (voltages, currents, temperature), temperature
monitor / alarm; board temperature sensor, power failure.
Mechanical • Single-width Full-Size (181.5 x 75 x 30.16 mm) or mid-size (181.5 x 75 x 18.96 mm)
Power Requirements
• Management power is less than 150mA peak at 3.3V
• Payload power is drive dependant
Environmental
Temperature*
• Operating: 0-55°C/32-131°F with HDD; 0-70°C/32-158°F with SSD
• Storage and Transit: -40 to +75°C/-40 to 167°F
Environmental
Humidity*
• Operating: 15% to 90% @55°C/131°F non-condensing
• Storage and Transit: 5% to 95% @ 40°C/104°F non-condensing
Environmental Altitude*
• Operating: 4,000 m / 13,123 ft
• Storage and Transit: 15,000 m / 49,212 ft
Environmental Shock*
• Operating: 30G, half-sine 11ms, each axis
• Storage and Transit: Bellcore GR-63-CORE Section 4.3
Environmental
Vibration*
• Operating: 1.0G, 5-500Hz each axis
• Storage and Transit: 0.5G, 5-50Hz; 3.0G, 50-500Hz each axis
Safety / EMC
• Meet or exceed:
• Safety: UL 60950-1 1st Ed.; CSA C22.2 No 60950-1-03; EN 60950-1:2001; IEC60950-1
• EMI/EMC: FCC 47 CFR Part 15, Class A; CE Mark to EN55022/EN55024
Warranty • Two years limited warranty
