NB PCIe Configuration
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PEG0
PEG0 – Gen X
PEG0 ASPM
Enable PEG
Detect Non-Compliance Device
De-emphasis Control
PEG Sampler Calibrate
Swing Control
Gen3 Equalization
Gen3 Eq Phase 2
Not Present
[Auto]
[Auto]
[Auto]
[Disabled]
[-3.5 dB]
[Auto]
[Full]
[Enabled]
[Auto]
Configure PEG0 B0:D1:F0
Gen1-Gen3
►
PEG Gen3 Root Port Preset Value for each Lane
► PEG Gen3 Endpoint Preset Value each Lane
► PEG Gen3 Endpoint Hint Value each Lane
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Gen3 Eq Preset Search
PEG Link Disabled
Fast PEG Init
RxCEM Loop back
► PCIe Gen3 RxCTLEp Setting
[Disabled]
[Disabled]
[Enabled]
[Disabled]
Version 2.15.1236. Copyright © 2012 American Megatrends, Inc
BIOS - Chipset
