KTQM67 Users Guide
KTD-N0819-K Page 54
6.9 LPT (Line Print Terminal – Parallel port) (J44)
The LPT connector (only KTQM67/Flex and KTQM67/ATXP) is a 32 pole single in line connector type
Tyco 3-1734592-2. Available cable kit (FFC cable and module), see chapter 8.
Pin
Signal
Description Type
Note
1
+5V
PWR Fused by 0.8A resetable PTC fuse
2
GND
PWR
3
RSV
Reserved
-
4
RSV
Reserved
-
5
RSV
Reserved
-
6
RSV
Reserved
-
7
NC
NC
8
RSV
Reserved
-
9
RSV
Reserved
-
10
RSV
Reserved
-
11
GND
PWR
12
AFD#
IS
13
STB#
IS
14
ERROR#
O
8mA load
15
PPD0
O
8mA load
16
INIT#
IS
17
GND
PWR
18
PPD1
O
8mA load
19
SLIN#
IS
20
PPD2
O
8mA load
21
PPD3
O
8mA load
22
GND
PWR
23
PPD4
O
8mA load
24
PPD5
O
8mA load
25
PPD6
O
8mA load
26
PPD7
O
8mA load
27
GND
PWR
28
ACK#
O
8mA load
29
BUSY
O
8mA load
30
PE
O
8mA load
31
SLCT
O
8mA load
32
GND
PWR
Signal
Description
AFD#
Auto Line Feed, active low
STB#
Strobe, active low
ERROR#
Error, active low
PPD0 – PPD7 Parallel Port Data0 – Data7
INIT#
Initialize, active low
SLIN#
Select Input, active low
ACK#
Acknowledge, active low
BUSY
Busy, active high
PE
Paper End, active high
SLCT
Select, active high
Internal Connectors
