KTD-N0800-0 Page 9
KT-PCIe-DVI-HDMI-I Users Guide
4 Connectors
HDMI connector
The HDMI connector is of type Samtec HDMI-19-01-S-SM or similar.
PIN Signal Type
Pull
U/D
1 TMDS Data 2+ LVDS OUT
2 GND PWR
3 TMDS Data 2- LVDS OUT
4 TMDS Data 1+ LVDS OUT
5 GND PWR
6 TMDS Data 1- LVDS OUT
7 TMDS Data 0+ LVDS OUT
8 GND PWR
9 TMDS Data 0- LVDS OUT
10 TMDS Clock+ LVDS OUT
11 GND PWR
12 TMDS Clock- LVDS OUT
13 CEC NC
14 NC NC
15 DDC Clock IO 2K2
16 DDC Data IO 2K2
17 GND PWR
18 +5V (55mA) PWR
19 Hot Plug Detect I
20-23 GND PWR
DVI-SIL
The “DVI” connector is a Hirose DF19G-20P-1H. Mating connector is Hirose DF19L-20P-1H or similar.
(In order to implement real DVI connector the cable kit 821524 must be used).
PIN Signal Type
Pull
U/D
1 GND PWR
2 GND PWR
3 +5V (55mA) PWR
4 Hot Plug Detect I
5 GND PWR
6 DDC Data IO 2K2
7 DDC Clock IO 2K2
8 GND PWR
9 TMDS Clock- LVDS OUT
10 TMDS Clock+ LVDS OUT
11 GND PWR
12 TMDS Data 0- LVDS OUT
13 TMDS Data 0+ LVDS OUT
14 GND PWR
15 TMDS Data 1- LVDS OUT
16 TMDS Data 1+ LVDS OUT
17 GND PWR
18 TMDS Data 2- LVDS OUT
19 TMDS Data 2+ LVDS OUT
20 GND PWR
Shield GND PWR
