820153 DC-DC Supply 10-25Vin 150W
KTD-00696-D Public User Manual Date: 2008-04-24 Page 9 of 9
Specifications
Input Requirements
Battery Driven Application Mode: 12V battery, 11.2 -24V (down to 8V for a few seconds is accepted).
Standard ATX Supply Mode: 10 – 25V regulated, max=15A.
The power input is protected against over-voltage transients, short circuits (>15A) and in Battery Driven
Application Mode the battery is protected against Deep Discharging.
Fuse: Littlefuse – MINIfuse 15A (Blue)
Voltage outputs
Output
voltage
Max Load / [A]
(Fan less)
Max Load / [A]
(Forced air)
Peak Load /
[A]
(<60 sec.)
Regulation
5V 6 8 12 +/- 1.5%
5VSB 1,5 1.5 2 +/- 1.5%
3.3V 6 8 12 +/- 1.5%
-12V 0,11 0.15 0.2 +/- 5%
12V 5,25 7 9 +/- 2%
Output Power: 150W (forced air) and 120W (Fan less) maximum.
Peak Load power: 200W < 0.5 sec.
Efficiency: >94% at 10 – 16V in and 50% load.
Lifetime: MTBF=192K hours at 50 ºC.
Size: (L, W, H) = (160, 45, 35) mm
Operating environment: Temperature: -20 to 85 ºC. Relative Humidity 10 to 90% (non-condensing).
Shipping and storage: Temperature -40 to +90 ºC. Relative humidity 5 to 95% (non-condensing).
RoHS compliant.
Longevity: For Embedded market. Earliest EOL August 2011.
PCB UL mark: E154554
