CP6004-RA/-RC
Introduction
ID 1055-1509, Rev. 1.0
Page 1 - 19
D R A F T — F O R I N T E R N A L U S E O N L Y
General
Mechanical
6U, 4HP, CompactPCI-compliant form factor
Power Consumption
See Chapter 5 for details.
Temperature Ranges
Operational temperature of CP6004-RA without TPM (with forced airflow):
•
CP6004-RA with Core™ i7-3612QE (SV): -40°C to +70°C
•
CP6004-RA with Core™ i7-3555LE (LV): -40°C to +70°C
Operational temperature of CP6004-RC without TPM:
•
Card edge temperature of CP6004-RC with Core™ i7-3612QE (SV) at the
maximum frequency of 2.1 GHz: -40°C to + 75°C
•
Card edge temperature of CP6004-RC with Core™ i7-3612QE (SV) at a
reduced frequency of 1.5 GHz: -40°C to + 85°C
•
Card edge temperature of CP6004-RC with Core™ i7-3555LE (LV) at the
maximum frequency of 2.5 GHz: -40°C to + 70°C
•
Card edge temperature of CP6004-RC with Core™ i7-3555LE (LV) at a re-
duced frequency of 1.8 GHz: -40°C to + 80°C
Operational temperature of TPM: -25°C to +70°C
Storage temperature of CP6004-RA without hard disk and without battery:
-40°C to +85°C
Storage temperature of CP6004-RC without hard disk and without battery:
-55°C to +105°C
Battery (CP6004-RA)
3.0V lithium battery for RTC with battery socket.
Battery type: UL-approved CR2025
Temperature ranges:
Operational: -20°C to +70°C
typical (refer to the battery manufacturer’s
specifications for exact range)
Storage: -55°C to +70°C
typical (no discharge)
Dimensions
233.35 mm x 160 mm
Board Weight
CP6004-RA:
725 g (with heat sink but without mezzanine cards)
CP6004-RC:
828 g (with heat sink but without mezzanine cards)
Table 1-2:
CP6004-RA/-RC Main Specifications (Continued)
FEATURES
SPECIFICATIONS
Note ...
When a battery is installed, refer to the operational specifica-
tions of the battery as this determines the storage tempera-
ture of the CP6004-RA (See "Battery" below).
Note ...
When additional components are installed, refer to their opera-
tional specifications as this will influence the operational and stor-
age temperature of the CP6004-RA/-RC.
