Introduction CP6004X-SA
Page 1 - 10 ID 1054-1227, Rev. 1.0
D R A F T — F O R I N T E R N A L U S E O N L Y
1.5 Technical Specification
Table 1-1: CP6004X-SA Main Specifications
FEATURES SPECIFICATIONS
Processor and Memory
CPU The CP6004X-SA supports the Intel® Core™ i7-3615QE (SV) quad-core pro-
cessor with 2.3 GHz and 6 MB L3 cache
Further processor features:
• Up to four execution cores
• Intel® Hyper-Threading Technology (Intel® HT Technology)
• Intel® 64 Architecture
• Intel® Advanced Vector Extensions (AVX) floating point
• Intel® Turbo Boost Technology 2.0
• Intel® Intelligent Power Sharing (IPS)
• System memory interface with optimized support for dual-channel
DDR3 SDRAM memory at 1600 MHz with ECC
• Integrated 2D and 3D Graphics Engines
• DMI 2.0 with 5 GT/s and FDI interfaces to the Intel® QM77 Chipset
• One x8 and two x4 PCI Express 2.0 ports operating at 5 GT/s
Please contact Kontron for further information concerning the suitability of
other Intel processors for use with the CP6004X-SA.
Memory Main memory:
• Up to 16 GB, dual-channel DDR3 SDRAM memory with ECC running at
1600 MHz on two SODIMM sockets
Cache structure:
• 64 kB L1 cache for each core
• 32 kB instruction cache
• 32 kB data cache
• 256 kB L2 shared instruction/data cache for each core
• Up to 6 MB L3 shared instruction/data cache
Flash memory:
• Two SPI boot flash chips (2 x 8 MB) for two separate uEFI BIOS images
• Up to 64 GB NAND flash via an onboard SATA Flash module (SSD)
Serial EEPROM with 64 kbit
