CP6003-RA/RC Introduction
ID 1046-3890, Rev. 1.0 Page 1 - 19
P R E L I M I N A R Y
General
Mechanical 6U, 4HP, CompactPCI-compliant form factor
Power Consumption See Chapter 5 for details.
Temperature Ranges Operational temperature of CP6003-RA without TPM (with forced airflow):
• CP6003-RA with Core™ i7-2715QE (SV): -40°C to +55°C
• CP6003-RA with Core™ i7-2655LE (LV): -40°C to +70°C
Operational temperature of CP6003-RC without TPM:
• Card edge temperature of CP6003-RC with Core™ i7-2715QE (SV) at the
maximum frequency of 2.1 GHz: -40°C to + 60°C
• Card edge temperature of CP6003-RC with Core™ i7-2715QE (SV) at a
reduced frequency of 1.7 GHz: -40°C to + 80°C
• Card edge temperature of CP6003-RC with Core™ i7-2655LE (LV) at the
maximum frequency of 2.2 GHz: -40°C to + 75°C
• Card edge temperature of CP6003-RC with Core™ i7-2655LE (LV) at a re-
duced frequency of 1.7 GHz: -40°C to + 85°C
Operational temperature of TPM: -25°C to +70°C
Storage temperature of CP6003-RA without hard disk and without battery:
-40°C to +85°C
Storage temperature of CP6003-RC without hard disk and without battery:
-55°C to +105°C
Battery (CP6003-RA) 3.0V lithium battery for RTC with battery socket.
Battery type: UL-approved CR2025
Temperature ranges:
Operational: -20°C to +70°C
typical (refer to the battery manufacturer’s
specifications for exact range)
Storage: -55°C to +70°C typical (no discharge)
Dimensions 233.35 mm x 160 mm
Board Weight CP6003-RA: 725 g (with heat sink but without mezzanine cards)
CP6003-RC: 828 g (with heat sink but without mezzanine cards)
Table 1-2: CP6003-RA/RC Main Specifications (Continued)
FEATURES SPECIFICATIONS
Note ...
When a battery is installed, refer to the operational specifica-
tions of the battery as this determines the storage tempera-
ture of the CP6003-RA (See "Battery" below).
Note ...
When additional components are installed, refer to their opera-
tional specifications as this will influence the operational and stor-
age temperature of the CP6003-RA/RC.
