Introduction CP6003-RA/RC
Page 1 - 14 ID 1046-3890, Rev. 1.0
P R E L I M I N A R Y
Chi
ps
et
Intel® QM67 Mobile Intel® QM67 Express Chipset:
• Two x4 or eight x1 PCI Express 2.0 ports operating at 5 GT/s (only one
x4 PCI Express port is used on the CP6003-RA/RC)
• SATA host controller with five ports and RAID 0/1/5/10 support
• One SATA 6 Gb/s ports accessible via an onboard connector
• Four SATA 3 Gb/s ports accessible via rear I/O
• USB 2.0 host interface with up to 14 USB ports available (only six ports
are used on the CP6003-RA/RC)
• Integrated Ethernet controller
• SPI flash interface support
• Low Pin Count (LPC) interface
• Power management logic support
• Enhanced DMA controller, interrupt controller, and timer functions
• System Management Bus (SMBus) compatible with most I²C™ devices
• DMI 2.0 with 5 GT/s and FDI interfaces to the processor
• High Definition Audio (HDA) interface
• Analog display port
• Three digital display ports
• Integrated RTC
Integrated Controller
Graphics controller High-performance 3D graphics controller integrated in the processor:
• Support for two independent displays
• Supports analog displays (CRT) up to a resolution of 2048 x 1536
pixels with 32-bit color @ 75 Hz
• Supports digital displays (HDMI/DVI) up to a resolution of 1920 x
1200 pixels @ 60 Hz
• Supports digital display (DP) up to a resolution of 2560 x 1600 pixels
@ 60 Hz
• Dynamic Video Memory Technology (DVMT)
Int
erfaces
CompactPCI Compliant with the CompactPCI Specification PICMG 2.0 R 3.0:
• System controller operation
• 64-bit / 66 MHz PCI or PCI-X master interface with dedicated PCIe-to-
PCI-X bridge
• 3.3V or 5V signaling levels (universal signaling support)
Compliant with the Packet Switching Specification PICMG 2.16.
The CP6003-RA/RC supports System Master hot swap functionality and appli-
cation-dependent hot swap functionality when used in a peripheral slot.
When used as a System Master, the CP6003-RA/RC supports individual
clocks for each slot and the ENUM signal handling is in compliance with the
PICMG 2.1 Hot Swap Specification.
When installed in a peripheral slot, the CP6003-RA/RC is isolated from the
CompactPCI bus. It receives power from the backplane and supports rear I/O
and, if the system supports it, packet switching (in this case up to two channels
of Gigabit Ethernet).
Table 1-2: CP6003-RA/RC Main Specifications (Continued)
FEATURES SPECIFICATIONS
