CP6003-RA/RC Introduction
ID 1046-3890, Rev. 1.0 Page 1 - 13
P R E L I M I N A R Y
1.7 Technical Specification
Table 1-2: CP6003-RA/RC Main Specifications
FEATURES SPECIFICATIONS
Processor and Memory
CPU The CP6003-RA/RC supports the following 2 nd generation microprocessors:
• Quad-core Intel® Core™ i7-2715QE (SV), 2.1 GHz, 6 MB L3 cache
• Dual-core Intel® Core™ i7-2655LE (LV), 2.2 GHz, 4 MB L3 cache
Further processor features:
• Up to four execution cores
• Intel® Hyper-Threading Technology (Intel® HT Technology)
• Intel® 64 Architecture
• Intel® Advanced Vector Extensions (AVX) floating point
• Intel® Turbo Boost Technology 2.0
• Intel® Intelligent Power Sharing (IPS)
• System memory interface with optimized support for dual-channel
DDR3 SDRAM memory at 1333 MHz with ECC
• Integrated 2D and 3D Graphics Engines
• DMI 2.0 with 5 GT/s and FDI interfaces to the Intel® QM67 chipset
• One x8 and two x4 PCI Express 2.0 ports operating at 5 GT/s
Please contact Kontron for further information concerning the suitability of
other Intel processors for use with the CP6003-RA/RC.
Memory Main Memory:
• Up to 16 GB, dual-channel, soldered DDR3 SDRAM memory with ECC
running at 1333 MHz
Cache Structure:
• 64 kB L1 cache for each core
• 32 kB instruction cache
• 32 kB data cache
• 256 kB L2 shared instruction/data cache for each core
• Up to 6 MB L3 shared instruction/data cache
Flash Memory:
• Two SPI flashes (2 x 8 MB) for uEFI BIOS and controlled by the IPMI
controller
• Up to 32 GB NAND flash via an onboard Serial ATA Flash module (SSD)
Serial EEPROM with 64 kbit
