The uEFI Shell CP6003-SA/RA/RC uEFI BIOS
Page 44 ID 1045-9149, Rev. 2.0
P R E L I M I N A R Y
SETTINGS: pxe: Select PXE boot device
[disabled]: No PXE boot available
all: Try all Ethernet devices round robin for PXE boot
gbe_a: CP6003-SA: try only front GbE A port
CP6003-RA: try either front GbE B port or rear LPc port
CP6003-RC: try only rear LPc port
gbe_b: CP6003-SA: try only front GbE B port
CP6003-RA: try either front GbE A port or rear LPd port
CP6003-RC: try only rear LPd port
rear_a: CP6003-SA/RA/RC: try only rear PICMG 2.16 LPa port
rear_b: CP6003-SA/RA/RC: try only rear PICMG 2.16 LPb port
gbe_e: CP6003-SA: try only front GbE E port
CP6003-RA: try only front GbE C port
CP6003-RC: function not supported
StorageOprom: Launch storage PCI option ROMs
disabled: Do not launch storage PCI option ROMs. This includes the
onboard RAID option ROM.
[enabled]: Launch storage option ROMs, if present
PrimaryDisplay: Select primary display device
[auto]: Automatically detect primary display device
igd: Use internal graphics, if enabled
peg: Try to use video on the PCIe graphics port, if present
pci: Try to use video on the PCI(e) bus first
Vga: VGA port configuration (CP6003-SA)
auto: Automatically detect devices. HDMI/DVI on rear I/O takes
precedence over front VGA if devices are connected to both front and
rear.
[front]: Try to use front VGA if available
rear: Try to use device connected to rear I/O if available
disabled: Disable graphic output
Note: “Auto” operation may fail if the monitor cable in use does not
correctly follow the VESA standard. For further information, refer
to the CP6003-SA User Guide, Chapter “Analog VGA
Connector”.
Note: This function is not relevant on the CP6003-RA/RC as the VGA
port is statically routed to rear I/O.
SETTINGS: SataMode: Determines how SATA controllers operate
ide: SATA ports operate as two IDE controllers
[ahci]: SATA ports operate as one 6-port AHCI controller
raid: SATA ports form a RAID device
kboardconfig (continued)
